WellData Medical
1 / 5
| Model | 14B | 17B | 23B |
|---|---|---|---|
| Chamber Dimensions (mm) (Φ×D) | 250×270 | 250×380 | 250×500 |
| Chamber Capacity (liter) | 14L | 17L | 23L |
| Overall Size (cm) (L×W×H) | 48×48×52 | 48×48×52 | 48×67×42 |
| Heater Power | 1600W | 1800W | 2000W |
| Net Weight (KGS) | 37 | 46.5 | 56 |
| Packing Size (cm) | 68×60×50 | 73×60×50 | 87×60×50 |
| Power Supply | 220V ± 10%, 50/60HZ, 10A | ||
| Sterilize Temperature | 121℃ / 134℃ | ||
| Dry Procedure | Vacuum drying | ||
| Chamber Construction | Stainless steel SUS#304 | ||
• Over heat control: Automatic power shut down and alarm when overheated.
• Over pressure control: Dedicated alarm system for over-pressure situations.
• Door lock: Automatic, Multi-Protection safety door lock system.
• Water level: Low water level indicator with alarm system.
• QC: 100% inspection and random checks on parts and machines.
• Warranty: 2 years warranty period with free maintenance parts.
• Service: Lifetime technical service support provided.
• Package: 1PCS/CTN; Transportation by air, sea, or express.
