Fully high-quality stainless-steel structure for durability.
Hand wheel type quick-open door structure for easy access.
Advanced door safety lock system to ensure operator safety.
Fully automatically controlled by integrated computer system.
Digital display showing real-time working status with touch-type keys.
Comprehensive over-temperature and over-pressure auto-protection.
Steam-water inner circulation system: No steam discharge, keeping the environment clean and dry.
Self-inflating type seal for reliable airtight performance.
Safe protection mechanism against water shortage.
Automatic shut-off with alarm beep reminding after sterilization completion.
Equipped with an efficient drying function.
Includes two stainless steel sterilizing baskets.
Technical Specifications
Chamber Volume
50L (φ340×550mm)
Working Pressure
0.22Mpa
Working Temperature
134ºC
Max. Working Pressure
0.23Mpa
Heat Average
≤±1ºC
Timer Range
0-99min or 0-99h59min
Temperature Adjust Range
0-134ºC
Power / Voltage
3kw / AC220V 50Hz
Overall Dimension
650×410×1140mm
Net/Gross Weight
83kg / 102kg
Product Detail Gallery
Frequently Asked Questions
Q: What is the main material of the MS-V50HM autoclave?
A: The entire structure, including the chamber and sterilizing baskets, is made of high-quality stainless steel for maximum hygiene and durability.
Q: Does the autoclave discharge steam during the process?
A: No, it features a steam-water inner circulation system that prevents steam discharge, ensuring the sterilization environment remains clean and dry.
Q: How do I know when the sterilization cycle is finished?
A: The unit is computer-controlled and will automatically shut off and emit a beep sound to alert you when the cycle is complete.
Q: What safety mechanisms are in place for high pressure?
A: It is equipped with over-temperature and over-pressure auto-protection, along with a secure door safety lock system that prevents opening under pressure.
Q: Can I adjust the sterilization temperature and time?
A: Yes, the temperature is adjustable up to 134ºC, and the timer can be set from 0 to 99 minutes or up to 99 hours and 59 minutes.
Q: Does it have a drying function for the sterilized items?
A: Yes, the MS-V50HM model includes a built-in drying function to ensure your equipment is ready for immediate use.
